Description
The ILS-3NM--laser cutting and laser engraving machine comes with the most mature, easy-to-use features of the ILS family. With A2-size working table, 210mm moving distance of Z-axis, and a flexible traversing-door design, it lets your operations work easily and efficiently. A built-in lighting design also allows users to reach an effective work-in-process observation. Moreover, the ILS-3NM is featuring reliable, quality, high-resolution, high-speed, and it is absolutely one of the best engraving solutions in the laser application era.
Features
ILS-3NM Laser cutting & laser engraving machine Standard:
Auto focus
Ethernet
Red-beam pointer
Options
- Rotary attachment
- Chop fixture
- Honeycomb cutting table with dust collector
- Honeycomb cutting table without dust collector
Specification
|
Model |
ILS-3NM-25W |
ILS-3NM-30W |
ILS-3NM-55W | ILS-3NM-60W | ILS-3NM-80W | ILS-3NM-100W |
| Laser Source |
25W air-cooled CO2 laser |
30W air-cooled CO2 laser |
55W air-cooled CO2 laser | 60W air-cooled CO2 laser | 80W air-cooled CO2 laser |
100W air-cooled CO2 laser |
| Max. Speed |
1524 mm/sec ( 60 inch/sec) |
|||||
| Resolution |
1000,500,333,250,200,167DPI |
|||||
| Working Area |
660(L) x 495(W)mm (25.98" x 19.48"inch) |
|||||
| Z-axis Moving |
Adjustable distance up to 210 mm |
|||||
| Max. Working Size |
640 (L) x (W) x 170 (H) mm |
|||||
| Memory Buffer | Standard 64MB, stores up to 99 files with all settings | |||||
| Computer Interface | Parallel port, Ethernet Port | |||||
| Application Software |
Windows compatible CAD, or graphics software |
|||||
| Operation Mode | Set up by driver, or operated by LCD control panel | |||||
| Power | 110/220VAC, 50-60Hz | |||||
| Dimension | 970 ( L ) x 865 ( W ) x990 ( H ) mm | |||||
| Regulatory | CDRH Class 1, CE CERTIFICATE | |||||
| Cooling | Air-cooled, ambient temperature operational range: 15 | |||||
