Description
The ILS-2 is a concise, versatile multi-functional laser engraving machine, which fits in flexible engraving/cutting processes to handle the customer's requirement of various requests, rapid product delivery, complicated graphics applications, etc. It is positioned as a high quality printer in the office; with great ease of use, and is appropriate for processing the gift items, trophies, chops, and various souvenirs, etc. The ILS-2 allows each user to work smoothly and effectively for laser engraving or laser cutting tasks; and importantly, to let customers own more creativity in the laser applications.
Features
- ILS-2 Laser cutting & laser engraving machine
- Options:
- Red beam pointer
- Rotary attachment
- Chop fixture
- Honeycomb cutting table with dust collector
- Honeycomb cutting table without dust collector
Specification
| Model | ILS-2-12W | ILS-2-30W | ILS-2-55W |
| Laser Source |
12W air -cooled CO2 laser |
30W air-cooled CO2 laser |
55W air-cooled CO2 laser |
| Max. Speed | 1000 mm/sec | ||
| Resolution (DPI) | 1000 , 500 , 333 , 250 , 200 , 167 DPI | ||
| Working Area | 410 x 295 mm | ||
| Z-axis Moving | Adjustable distance up to 130 mm | ||
| Max. Working Area | 490 (L) x 360 (W) x 130 (H) mm | ||
| Memory Buffer | Standard 64MB; stores up to 99 files | ||
| Computer Interface | Parallel port; compatible with Windows software | ||
| Application Software | Windows compatible CAD, or graphics software | ||
| Operation Mode | Set up by driver, or operated by LCD control panel | ||
| Dimension | 630 x 740 x 563 mm | 630 x 760 x 563 mm | 622 x 638 x 1139mm |
| Power | 110/220VAC, 50-60Hz | ||
| Regulatory Compliance | CDRH Class I, CE CERTIFICATE | ||
| Cooling | Air-cooled, ambient temperature | ||
